XSFL603616D15

60H × 36W × 16D – Flanged Disconnect Single-Door Enclosure

With Hygienic Defeater Handle and Patented Double Seal & Double Stud Technologies

Specifications

• Enclosure Height: 65.42″
• Door Height: 60.00″
• Width: 36.00″
• Depth: 16.00″
• Pitch: °15.00 Sloped Forward
• Weight: 269.27 lbs
• Enclosure Type: Flanged Disconnect Single-Door
• Thickness: 14 gauge
• Material: AISI 304 Stainless Steel
• Compatible Back Panel: X60P36G (Galvanized)
• Finish: Brushed #4 Outside w/ 2B Inside Finish
• Latch Method: Hygienic Defeater Handle
• Hinge Type: Hygienic Bullet Hinge
• Seal Design: Patented Double Seal Technology
• Mount Type: Patented 3/8"-16 UNC Double Stud Wall-Mount

• Gasket Material: Blue EPDM - Field Replaceable
• Includes: Grounding Hardware; Printer Pocket


Built Tougher Than The Rest

Our washdown ratings surpass competing models, fully matching or exceeding the performance of WS60HS3716SS.
